MCS 600 Network Connection
MCS 600
4.2 Embedding the MCS 600 in a company network
with a DHCP server
Request a fixed IP address, subnet mask and gateway for the MCS 600 from your
administrator. Configure your settings using these values in accordance with one
of the methods provided in section 4.3.
Then, configure your measuring computer's network adapter as follows: Adminis-
trator rights are needed to change these settings. If you do not have administra-
tor rights, contact your administrator.
The following information applies to Windows 7:
1. Press the Windows button and enter "Network connections".
2. Select "View network connections".
3. Double-click on the network adaptor you want to connect to the MCS 600.
Note
If you have multiple network adapters, you can identify the correct
adapter by disconnecting and reconnecting the network cable several
times. This will change the adapter's connection status.
4. In the dialog window, select "Internet Protocol Version 4 (TCP/IPv4)".
5. Click the "Properties" button.
Note
Before changing the settings on your PC's network adapter, make a
note of the original settings so that you can reset them at a later point
in time.
6. Select "Obtain an IP address automatically".
