Troubleshooting
6.4
Understanding BMS Flash Code Patterns (Charge Mode)
This mode is with the charging cord plugged into the AC power, and the key in the OFF position. During the Charging
process, first all lights will flash. Next, lights 1 through 4 will flash depending on the power pack’s state of charge.
1 RED 2 GREEN 3 GREEN 4 GREEN ON OFF MEANING SOLUTION
1 sec 5 sec Charge Complete Unplug Charger
Charging
250 ms 25% Continue Charging
250 ms 50% Continue Charging
250 ms 75% Continue Charging
250 ms 100% Continue Charging
Balancing
500 ms
Power Pack Unbalanced Let the Power Pack Cool Down
500 ms
Temperature Disable
100 ms 500 ms Too Hot Let the Power Pack Cool Down
