Zero FX User Manual

Maintaining Your Motorcycle
5.5
Component Fasteners
Periodically check and tighten the following fasteners on your motorcycle.
Torque Table
LOCATION ITEM TORQUE NOTES
A Front axle end bolts 19 lb ft (26 Nm) Use LOCTITE® 242® (or equivalent)
B Front caliper mount bolts 12 lb ft (20 Nm) Use LOCTITE® 242® (or equivalent)
C Main pivot bolt/nut (swingarm) 55 lb ft (75 Nm) Use LOCTITE® 242® (or equivalent)
D Shock mount bolts (upper/lower) 52 lb ft (70.5 Nm)/ 38 lb ft (51.5 Nm) -
E Rear caliper mount bolts 15 lb ft (20 Nm) Use LOCTITE® 242® (or equivalent)
F Rear axle end bolt 19 lb ft (26 Nm) Use LOCTITE® 242® (or equivalent)
G Rear axle pinch bolts 19 lb ft (26 Nm) Use LOCTITE® 242® (or equivalent)
H Motor mount bolts (rear) 19 lb ft (24 Nm) -
I Motor mount bolts (front) 22 lb ft (30 Nm) -
J Triple tree pinch bolts 11 lb ft (15 Nm) -
K Front axle pinch bolts 13 lb ft (18 Nm) -
L Handlebar clamp mount bolts 19 lb ft (26 Nm) -
Zero Owner's Manual (X, MX and XU).book Page 5 Monday, April 29, 2013 3:30 PM

Zero FX Specifications

General

Category	Electric Motorcycle
Max Battery Capacity	7.2 kWh
Top Speed	85 mph (137 km/h)
Max Power	46 hp (34 kW)
Peak Torque	78 ft-lb (106 Nm)
Battery	Z-Force Li-Ion
Front Suspension	Showa 41 mm inverted cartridge fork
Rear Suspension	Showa piggyback reservoir shock
Front Brake	Single 320 mm disc with J-Juan 2-piston caliper
Rear Brake	Single 240 mm disc with J-Juan 1-piston caliper
Motor	Z-Force® 75-5 passively air-cooled, high efficiency, radial flux, interior permanent magnet, brushless motor
