Zero FX User Manual

General Operation
4.4
Key Switch/Steering Lock Positions
This is a three-position switch that is located on the fork in
front of the handlebar. The switch positions are as follows:
A. Steering Lock
B. OFF
C. ON
The key should be removed from the motorcycle when
parked to prevent theft. The key can be removed in either
the OFF or steering lock position.
Steering Lock
Using the steering lock when parked will prevent
unauthorized use and help prevent theft.
To operate the steering lock:
1. Turn the handlebar all the way to the left.
2. Push the key down from the OFF position and turn the
key counter-clockwise while still pushing it in.
3. Remove the key.
To unlock the steering lock:
1. Install the key and turn clockwise.
2. Remove the key.
I
G
N
I
T
I
O
N
OFF
ON
B
C
A
Zero Owner's Manual (X, MX and XU).book Page 4 Monday, April 29, 2013 3:30 PM

Zero FX Specifications

General

Category	Electric Motorcycle
Max Battery Capacity	7.2 kWh
Top Speed	85 mph (137 km/h)
Max Power	46 hp (34 kW)
Peak Torque	78 ft-lb (106 Nm)
Battery	Z-Force Li-Ion
Front Suspension	Showa 41 mm inverted cartridge fork
Rear Suspension	Showa piggyback reservoir shock
Front Brake	Single 320 mm disc with J-Juan 2-piston caliper
Rear Brake	Single 240 mm disc with J-Juan 1-piston caliper
Motor	Z-Force® 75-5 passively air-cooled, high efficiency, radial flux, interior permanent magnet, brushless motor
