Zero FX User Manual

General Information
1.7
DRIVETRAIN
Transmission Clutchless Direct Drive
Final Drive 132T/25T, Poly Chain® GT® Carbon™
(belt)
CHASSIS/SUSPENSION/BRAKES
Front Suspension Travel 3.2 in/240 mm
Rear Suspension Travel 8.9 in/227 mm
Front Brakes 221 mm OD rotor, 4.5mm thick
Nissin 2 piston floating caliper, 27mm OD
piston
12.7 mm bore Fr Master Cylinder
Rear Brakes 221 mm OD rotor, 4.5mm thick
Nissin single piston floating caliper, 25.4mm
OD piston
12.7 mm bore Fr Master Cylinder
Front Tire 3.00-21 in (90/90-21)
Rear Tire 4.10-18 in (110/90-18)
Front Wheel 1.60x21 in
Rear Wheels 2.15x18 in
Front Suspension 38mm OD steel stanchions, 48mm OD
outer tube clamping diameter. Inverted
forks with adjusted compression and
rebound damping
Rear Suspension Piggyback reservoir shock with adjustable
spring preload, compression and rebound
DIMENSIONS
Wheel Base 56.6 in (1,438 mm)
Seat Height 35.4 in (899 mm)
Rake 26.1 degrees
Trail 4.4 in (112 mm)
WEIGHT
Frame 17 lbs (7.7 kg)
Curb Weight  ZF2.8 233 lbs (106 kg)
 ZF5.7 275 lbs (125 kg)
Carrying Capacity  ZF2.8 347 lbs (157 kg)
 ZF5.7 305 lbs (138 kg)
ECONOMY
Typical Cost to Recharge  ZF 2.8: $ 0.3/€ 0.43
 ZF 5.7: $ 0.6/€ 0.85
Equivalent Fuel Economy
(city)
 470 MPGe(0.50 L/100 km)
Equivalent Fuel Economy
(highway)
 ZF 2.8: 207 MPGe (1.14 L/100 km)
 ZF 5.7: 212 MPGe (1.11 L/100 km)
Chapter 1.fm Page 7 Monday, April 29, 2013 4:01 PM

Zero FX Specifications

General

Category	Electric Motorcycle
Max Battery Capacity	7.2 kWh
Top Speed	85 mph (137 km/h)
Max Power	46 hp (34 kW)
Peak Torque	78 ft-lb (106 Nm)
Battery	Z-Force Li-Ion
Front Suspension	Showa 41 mm inverted cartridge fork
Rear Suspension	Showa piggyback reservoir shock
Front Brake	Single 320 mm disc with J-Juan 2-piston caliper
Rear Brake	Single 240 mm disc with J-Juan 1-piston caliper
Motor	Z-Force® 75-5 passively air-cooled, high efficiency, radial flux, interior permanent magnet, brushless motor
