Zero FX User Manual

General Operation
4.7
Power Pack Swapping
The motorcycles feature a quick change power pack. This
allows the rider to charge one power pack while using
another. Do not operate the motorcycle without the power
rail or rail fastener in place. To change the power pack,
perform the following:
To remove the power pack:
1. Remove the key from the key switch and safely support
the motorcycle.
2. Grasp the bottom of the key lock (arrow) and pull
upward to unlock the power pack rail.
3. Pull the power pack rail (A) away from the motorcycle.
4. Using a firm grip, slide the power pack out of the frame.
DO NOT lift the power pack by the plastic connector
housing.
NOTE: The power pack weighs 53lbs (24 kg).
To Install the power pack:
1. Slide the power pack into the frame.
2. Re-attach the power pack rail.
3. Push the key lock downward to secure the rail.
4. (Optional) Use the key to lock the rail.
ZOM0068
Zero Owner's Manual (X, MX and XU).book Page 7 Monday, April 29, 2013 3:30 PM

Zero FX Specifications

General

Category	Electric Motorcycle
Max Battery Capacity	7.2 kWh
Top Speed	85 mph (137 km/h)
Max Power	46 hp (34 kW)
Peak Torque	78 ft-lb (106 Nm)
Battery	Z-Force Li-Ion
Front Suspension	Showa 41 mm inverted cartridge fork
Rear Suspension	Showa piggyback reservoir shock
Front Brake	Single 320 mm disc with J-Juan 2-piston caliper
Rear Brake	Single 240 mm disc with J-Juan 1-piston caliper
Motor	Z-Force® 75-5 passively air-cooled, high efficiency, radial flux, interior permanent magnet, brushless motor
