Zetor Forterra HD 150 User Manual

Technical data of engines
ECE R24 - engine equipped with accessories - cooling ventilator
Tractor type FORTERRA HD 130 FORTERRA HD 140 FORTERRA HD 150
Engine type 1516 1616 1716
Engine kind diesel, four-stroke with direct fuel injection, turbocharged
Engine design in-line, vertical, water cooled
Engine revolutions
control
electronic
Number of cylinders 4
Displacement
cm
3
4156
Bore x stroke mm 105x120
Nominal speed rpm 2200
Injection sequence 1-3-4-2
Compression ratio 17
Max. overspeed rpm 2460
Idle speed rpm 800 ± 25
Net power at the
nominal speed (ECE
R24)
kW 88 95 103
Fuel consumption at the
nominal engine speed
(2200 rpm) (ECE R24)
g/kWh 239 240 246
Max. torque (1,480 rpm)
(ECE R24)
Nm 540 570 578
Inclination Mt (ECE R24) % 41 38 29
Fuel consumption at the
maximum torque (1,480
rpm) (ECE R24)
g/kWh 211 212 210
Engine lubrication pressurized with a Gerotor pump
Maximum consumption
of oil after 100 hours of
engine running-in
g/kWh 0,5
Oil pressure at the
nominal engine speed
and the oil temperature
of 80°C
MPa 0,3 - 0,5
Minimum oil pressure at
the engine speed of 750
rpm and oil temperature
of 80°C
MPa 0,08
Max. coolant
temperature
°C 106
Timing type OHV
Timing angle ° 12
Valve clearance with the
engine cold
- suction
- exhaust
mm
mm
0,3
0,3
MAIN TECHNICAL PARAMETERS
155155

Zetor Forterra HD 150 Specifications

General

Rated engine speed	2200 rpm
Weight	5800 kg
Max Speed	40 km/h
Fuel Tank Capacity	270 l
PTO Speed	540/1000 rpm
Engine Power	150 HP
