Stopping rear PTO shaft
Rear PTO shaft stops if the arms of three-point hitch are lifted higher than H-LIMIT is set. When stopping
rear PTO shaft, the display of symbol (B) starts blinking on the display.
Restarting rear PTO shaft
For subsequent spinning of rear PTO shaft it is necessary to proceed in accordance with see Starting rear
PTO shaft.
If with Stopping rear PTO shaft also stopping of tractor occurs which lasts for more than three minutes,
there is a blockage of starting rear PTO shaft. (B) symbol is not displayed on the display, control on switch
(A) is blinking and PTO shaft does spin also when meeting the conditions for Starting rear PTO shaft.
If there is a blockage of blocking the starting of rear PTO shaft, it is necessary to switch the switch to (A)
position - off. Then switch the rear PTO clutch again by switch A according to previous articles.
Front PTO shaft
Front PTO shaft control
Front PTO shaft is equipped with a solid six or twenty-one
splined end point and it comes only in design of 1,000
revolutions.
Tractor may be equipped with front PTO shaft with varied
direction of spinning:
a - In compliance with the direction
of engine revolutions (standard)
b - Against the direction of engine
revolutions (*on request)
F_02_64
Engagement and disengagement of front PTO shaft is
done by a switch (4) The switch is equipped with
a mechanical lock (2) against unwanted switch. When
switching the switch depress the lock in the downward
direction.
Front PTO shaft is set into activity by switch of a switch.
FHD14N019
The engagement of front PTO shaft is signalized by
displaying the number of revolutions of front PTO shaft on
the display of dashboard.
If the aggregated machine permits, engage
front PTO shaft with min. engine revolutions of 1500
rpm.
FHD14N020
DRIVE OF AGRICULTURAL MACHINERY
