Button-Based Consoles
9
Introduction
This manual divides operation into two main chapters: one for button-based consoles
(such as the Model 4018 or 4118) and one for IntegratorRD consoles.
Button-Based Consoles
The Series 4000 Communication Control System provides a means for one or more
dispatchers to efficiently control a radio system composed of up to 24 radio channels. It is
suitable for use in public safety applications, such as police and fire communications, as
well as public service applications, such as utility and industrial communications. Its
unique features allow it to be tailor-fit for any of these broad-ranging requirements.
Common Control Equipment
The Model 4048 and Model 4020 Common Control Equipment (CCE) are part of the
Series 4000 Communication Control System. They enable one or more dispatchers to
control a multi-channel radio system efficiently.
The CCE is the central interface that routes signals between radio channels and dispatch
consoles. The Model 4048 contains up to 48 modular circuit cards. It handles up to 48
radio channels and up to 16 dispatch console positions. The Model 4048 is typically
installed near the radio base station and telephone line terminations.
