Installation and Balance Adjustment
Installing the camera
1.Mount the camera on the camera backing base and quick release plate, and
tighten the bottom screw. Mount the lens support to the front end of the quick
release plate and tighten the screw.
You may decide whether or not to use the camera backing base depending
on your camera-lens combo. You will need the camera backing base in the
following situations:
① When using smaller and lighter cameras, such as the Sony 6000 series
cameras.
② When using lenses with larger diameters, such as the Canon RF28-70mm F2
L USM lens.
③ When installing the TransMount Follow Focus Motor.
④ If it is difficult to balance the roll axis when the camera is mounted vertically.
2. Adjust the lens support on the quick release plate so that it can hold the lens.
Ensure that the lens is stable.
3. Install the quick release plate with the mounted camera onto the gimbal, and lock
the quick release plate.
To avoid mechanical noises from the gimbal, tighten the vertical locking screw
when mounting in horizontal mode; when mounting in vertical mode, tighten the
quick release base locking latch; and you may choose whether or not to install
the quick release base depending on the shooting conditions.
Horizontal mount Vertical mount
