4
Installation and Balancing
Mount the stabilizer on the tripod and unfold the
tripod on a flat surface.
Tripod Installation
Camera Installation
Take Sony DSC-RX100M5 as example:
1. Take out the quick release plate, mount the camera on the plate and then tighten the
1/4" screw at its bottom.
2. Loosen the quick release plate thumb screw, slide the camera-mounted quick
release plate to the quick release module. Push the quick release plate towards the tilt
axis motor but not to rub the motor. Tighten the quick release plate thumb screw after
the safety lock is engaged.
① Long slot of the quick release plate is for installing
mirrorless camera, while the short slot is for compact
camera (Fuji mirrorless cameras can be installed in
the short slot).
② Before mounting the camera, make sure the
camera is ready for work. Remove the lens cap and
make sure the camera’s battery and memory card
are already inserted.
The pan axis motor has a latch to lock and unlock the pan axis. Please unlock the pan
axis before using the stabilizer and lock it when not in use.
For storage, fold the arms (axes) in order as shown in the picture below; Press down
and stick roll axis to pan axis by the locking pin; Tighten the roll axis thumb screw to
finalize.
Long Slot Short Slot
