Zhiyun CRANE-M2 User Manual

12
How to Use
Control Mode Description
Red circle means the motor’s rotation follows the movement of the stabilizer handle
while grey circle means the motor’s rotation is independent from the handle’s
movement.
Pan Following Mode (PF): Single click
Mode Button to switch to this mode.
Camera pans left/right following the
movement of the stabilizer handle while
the tilt and roll axis motors are locked.
Push the joystick up/down to control the
tilt axis manually.
Locking Mode (L): Single click Mode
Button to switch to this mode.
This mode locks the movement of all
three axes and the orientation of the
camera is fixed. Push the joystick to
control the orientation of the camera
manually.
POV Mode (POV): Single click Mode
Button to switch to this mode.
All three axes move following the
movement of the stabilizer handle.
Go Mode (GO): Double click Mode
Button to switch to this mode.
The camera pans left/right and tilts up/
down following the movement of the
stabilizer in fast speed while the roll axis
motor is locked.
俯仰轴
航向轴
横滚轴
横滚轴
俯仰轴
航向轴
航向轴
横滚轴
俯仰轴
俯仰轴
横滚轴
航向轴
Roll Axis
Tilt Axis
Pan Axis
Roll Axis
Tilt Axis
Pan Axis
Roll Axis
Tilt Axis
Pan Axis
Roll Axis
Tilt Axis
Pan Axis

Zhiyun CRANE-M2 Specifications

General

Weight	500g
Tilt Angle Range	310°
Roll Angle Range	324°
Pan Angle Range	360°
Following Deviation in Motion State	±0.05°
Compatible Devices	Smartphones, action cameras, compact cameras
Stabilization	3-Axis
Payload	720g
Battery Type	Built-in lithium-ion battery
Mounting Options	1/4\"-20 Mounting Hole
Operating Voltage	12.6 V
Control Interface	buttons
Follow Modes	POV, Vortex
Battery Runtime	7 hours
