ZiLOG eZ80 User Manual

eZ80
®
CPU
User Manual
UM007714-0908 CPU Instruction Set
245
LEA rr, IY+d
Load Effective Address
Operation
rr ← IY+d
Description
The rr operand is any of the multibyte CPU registers BC, DE, or HL. The CPU adds the
contents of the IY register to the signed displacement
d and writes the sum to the multi-
byte
rr register.
Condition Bits Affected
None.
Attributes
kk identifies either the BC, DE, or HL multibyte register and is assembled into one of the
opcodes indicated in Table 74.
Mnemonic Operand ADL Mode Cycle Opcode (hex)
LEA rr,IY+d X3ED, kk, dd
LEA.S rr,IY+d 1452, ED, kk, dd
LEA.L rr,IY+d 0449, ED, kk, dd
Table 74. Register and kk Opcodes for LEA rr, IY+d Instruction (hex)
Register kk
BC 03
DE 13
HL 23
