1
Overview
19.80mm
143mm
85mm
Breathing Light
2.4-inch Color Screen
Hidden Touch Keypad Speaker
Terminal Block
12V-OUT
485A
485B
WD0-OUT
WD1-OUT
INWD0
INWD1
GND
TX232
RX232
NC
COM
NO
SEN
GND
BUT
AUX
BELL+
BELL-
AL+
AL-
TX+
RX+
TX-
RX-
12VIN
PGND
PGND
Reset
