ZKTeco SC800 Quick Start Guide

Ethernet Connection
Tap on [COMM.] > [Ethernet] > [IP Address] the IP address and tap on [OK]., then enter
IP address: 192.168.1.130
Subnet mask: 255.255.255.0
Default IP address: 192.168.1.201
Subnet mask: 255.255.255.0
Connect the device and computer over an Ethernet cable as shown in the figure:
Note: In LAN, the IP addresses of the server (PC) and the device must be in the
same network segment when connecting to the software.
Wiegand Reader Connection
Note: 485A and 485B can be connected to the Barrier gate or the 485 Reader,
separately, but cannot be connected to the gate and reader at the same time.
4
ZKBio Access IVS
ZKBioTime 8.0
WD0
WD1
485A
485B
WD0-OUT
WD1-OUT
INWD0
INWD1
GND
12V-OUT
Wiegand
Reader
+12V
GND
WD1
WD0
Access
Controller
TX232
RX232
