18
2.6.3. pH pump connecon (for pH - PH/ORP models)
• Above 500mA, the pH pump connecon must be protected by a circuit breaker with a suitable residual
current protecon device and controlled using a relay.
Installaon with
provided pH
pump
Alternave
soluon if a
bigger pump is
used
pH pump fuse: 5x20 T 500 mA/250V
pH pump (included)
pH pump >500 mA (not included)
230V relay
