29
4.3.10. “Pump stop”: pH pump stop over feed alarm (pH - PH/ORP models)
The pH pump stops rotang if the pH setpoint has not been reached aer a given me, resulng in the display of an
alarm. By default, this programmed safety me is 60 minutes. To adjust it (minimum value: 1 min - maximum value:
120 min):
• From the Conguraon/Pump stop mode, press : “OFF” ashes
• Press to switch to “ON”. The injecon me ashes.
• Press or to adjust this value.
• Press to conrm.
4.3.11. "Auto Cl mV": Automac ORP regulaon (pH/ORP models)
This mode is activated by default on pH/ORP models only. Production stops when the setpoint is passed. To deacvate
the automac mode:
• From the Conguraon/Auto Cl mV mode, press : "ON" ashes.
• Press to acvate it ("OFF").
• Press to conrm.
4.3.12. "Cl EXT": Slave mode
• Ensure that these appliances are properly connected to the power supply in accordance with
the regulaons in force and are protected by a circuit breaker (ltraon unit).
Slave mode transfers control over the chlorinaon funcon to an external controller (ORP or ppm control). Once the
external controller is correctly connected to the connecon point (see § “2.6.2. Detail of connecons”), acvate the
Slave mode:
• From the Conguraon/Cl EXT auto mode, press : "OFF" ashes.
• Press to acvate it ("ON").
• Press to conrm.
•
