6.2Replacingthebrushes

 ThecleanerisfittedwithPVCbrushes.Theyhavewearindicators(1).
 Toremovewornbrushes,removethetabsfromtheholesinwhichtheyarefixed.
 Tofitnewbrushesstartbyfittingthesidewithouttabsunderthebrushholder(2).
 Rollthebrusharounditssupportandslidethetabsin
tothefixingholes(3).
 Pullontheendofeachtab(4)untilitsedgepassesthroughtheslit.
 Cutthetabsusingscissorssothattheyareatthesamelevelastheotherblades(5).







6.3Changingthebands







6.4.Maintenanceofyourcleaner


 Thecleanermustbecleanedregularlyusingcleanorslightlysoapywater,donotusesolventssuch
as trichloroethylene or its equivalent. Rinse the cleaner generously using clean water. Do not let
yourcleanerdryinthesunbythepool.
 Thecleanermustbestoredonthecad dyprovidedforthisusesothatitdriesquickly.
 Windthecab
learoundthehooks.

6.5Recycling
This symbol on a new appliance means that the equipment must not be thrown away, it will be selectively
collected for the purpose of reuse, recycling or creating value. If it contains substances that are potentially
harmfultothe environment,they will be eliminatedorneutralised.Askyourresellerabouthowtorecy
cleyour
applianceandthebod
iesthatcandoso.

7.Troubleshooting

7.1Meaningoferrorcodesandpossiblecauses

 Vortex™3.2=ControlindicatorLedBLINKS

 Ifthe Ledisoff,thecleanerisoperatingnormally.Itisnotcommunicatinganyinformation.
 Ifthe
Ledisblinking,thecleanerissignallingthatyoushouldperformcheckstoimprovecleaning.

 Vortex™34WD,Vortex™44WD=Intheeventofmalfunction,thecontrolboxindicatestheerrorcode
onthescreen.

 Pressingakeydeletestheerrorcodeandturnsoffthecontrolbox.
 Thescreenswitchestostandbyafter10minutes.Toturnthescreenbackon,justpressanykey.
 Whenanerrorisdetected,thecontrolboxtemporarilysuspendstheprogramme(the
ledisturnedoff).
Pressthe
keyforalongerperiodtorevalidatethecurrentprogramming.

Werecommendthatyoureplacethebrusheseverytwoseasons.









