Zodiac Vortex 3.2 User Manual


H03839‐00.B2EN–2013‐09
 13
7.3Pre‐diagnosisintheeventofamalfunction(Vortex™34WD,Vortex™44WD)


8.Productcompliance

Thisappliancehasbeend esignedandbuiltaccordingtothefollowingstandards:

Lowvoltagedirective:2006/95/EC
Electromagneticcompatibilitydirective:2004/108/EC
EN55014‐1:2000+A1:2001+A2:2002;EN55014‐2:1997+A1:2002
EN60335‐1:2002+A1:2004+A2:2006+A11:2004+A12:2006;EN60335‐2‐41:2003+A1:2004

Relativetowhichitiscompliant.
Theproducthasbeentestedunderthenormalconditionsofuse.

ZodiacPoolCareEuropeherebydeclaresthatthisproductisincompliancewiththeessentialrequirementsand
otherpertinentdispositionsoftheR&TTE1999/5/ECdirective 


SAFETYSTANDARDS:
ThecleanersareclassifiedbytheETLasbeingcompliantwiththeappropriaterequirementsof 
IEC60335‐2‐41.





Ifyourcleanermalfunctionsyouhaveaccesstoamenuwhichgivessomeindicationsonthestatusofyour
cleaner.Thisinformationcanbeusedbyyourresellertotroubleshootapossiblebreakdown.
Toaccessthemenuthecleanermustnotbeoperationalandthedisplaymustbeon.
Presson and simultaneouslyforatleast5seconds.

Thisistheinformationthatisdisplayedinorderevery3seconds:
 Thetotalcleaneroperatingtime(inhours),exampledisplay: 
 Thelastcleanererrorcode(ifthecleanerhashadatleastoneerror),exampledisplay: 
 Thecleaneroperatingtimeattheerror(ifthecleanerhashad atleastoneerror),exampledisplay:


Oncethisinformationhasbeendispl ayed,thecontrolboxreturnstothemenu,withthescreenon:


