Zodiac Vortex 3.2 User Manual


H03839‐00.B2EN–2013‐09
 4
Surfaceareatobecleaned*
Bottomonly
Bottom+sides+waterline

1.5Immersingthecleaner

 Placethecleanerverticallyintothewater(1)andmoveitslightlyinalldire ctionssothattheaircontainedinthe
cleanerescapes(2).
 Itisessentialthatthecleanersinksonitsownandsettlesonthepoolbottom.Spreadouttherequiredlengthof
cablebythepool.Foroptimumoperationwerecommendthatyo
upla
cethecaddy withthecon trolboxatthe
centreofthepoollength(3).









1.6Electricalconnection


 Unscrewtheprotectivecap.

 Connectthefloatingcabletothecontrolbox(1)andlockitintoplace:firmlytighten
theringbyturningitclockwise(2).Makesuretheconnectoris sufficientlypushedinto
place.Ifthisisnotthecaserepeattheoperation.

 Connectthemainscable.Onlyconnectthecontrolboxtoapoweroutletprotected
by a 30 mA maximum ground fault circuit breaker (if in doubt contact a qualified 
electrician).



2.Descriptionofthecontrolbox

2.1Vortex™3.2

Donotallowbathingwhenthecleanerisinthepool.

Place the control box on the caddy at a distance of at least 3.5 metres from the edge of the pool
avoidingplacingthecontrolboxindirectsunlight.

Don’t forget to screw the protective cap back on if you unplug the control
boxpowercord.

*Theselectedcleaningcyclecanbeidentifiedviatheiconsthataredisplayed







"Control"indicator

Start/Stopthecleaner
Removalfrompoolmode

