12
240 VAC LINE DIAGRAM
AUTOMATIC TRANSFER SWITCH
Location: Under Lounge
REDARC INVERTER
Location: Under Lounge
BATTERY ISOLATOR
Location: Under Lounge
RCD - ADJACENT INLET
LITHIUM BATTERY
240VAC
240V Outlets
