POP TOP
Your Zone RV Expedition is equipped with an electrically actuated pop top roof to minimise
height whilst travelling. The control switch for the roof actuators is located under the
awning switch, inside the entry door on the left hand side. Pressing the rocker switch at
the top raises the roof.
Note: The caravan must only be used in either the fully down or fully up positions.
Caution: Ensure that the roof is fully lowered when travelling. Failure to do
so may result in damage to the caravan and will void warranty.
RAISING THE ROOF
Prior to raising the roof, the van must be parked, levelled and stabilised.
1. Open the entry door and enter the van to turn on the power via the REDARC
display panel.
2. Whilst standing outside the van, press and hold the switch until the roof reaches
its maximum height, approximately 600mm above the lowered position. The
actuators will automatically cut out when this position is reached.
POP TOP SWITCH
