18
GREY WATER BY-PASS
Location: Drivers side of van, behind rear wheel, next to grey water
In situations where it is not necessary to retain grey water, the grey water bypass may be
used. This directs grey water straight to the camlock fitting rather than going via the tank.
• Attach the supplied grey water hose to the cam lock fitting.
• Turn the Bypass valve to the Closed position.
• Turn the Grey Water Outlet valve to the open position.
TOILET
Your Zone RV caravan is fitted with a OGO Composting Toilet.
For more information, please refer to OGO Composting Toilet manual.
Diagram shows position of valves when retaining grey water (Not using bypass).
Closed Valve
Open Valve
Bypass Valve
Grey Water
Outlet
Grey Water In
PLUMBING GENERAL
