Zoom 2020 - Specifications

The 2020 reverts to the normal Play mode, and patch selection is possible.
ZOOM PLAYER 2020
Number of effect programs: 19 types (5 modules)
A / D conversion: 16-bit 64-times oversampling MASH converter
D / A conversion: 16-bit linear
Inputs:
Guitar input Phone Jack (Mono) x 1
(nominal input level -20 dBm, input impedance 470 kΩ)
Outputs: Line Phone Jack (Mono) x 2
Headphones (also recording output): Mini phone jack (Stereo)
PHONES (output power 35 mW into 32 ohms)
REC OUT (nominal output level -20 dBm,
recommended load impedance 10 KΩ or more)
Tuner out Phone Jack (Mono) x 1
(nominal output level -20 dBm,
recommended load impedance 47 KΩ or more)
Control connectors: Foot pedal input
Manual mode foot switch / wah control input
Display: 2-character, 7-segment LED display
Power supply: 9 V DC, 150 mA (from supplied AC adapter)
Dimensions:
300 x 210 x 42 (W x D x H)
Weight: 1.2 kg
* 0 dBm=0.775 Vrms
* Design and specifications subject to change without notice.
20
Specifications
