Zoom G1 User Manual

No. NAME SUB SPECIFICATIONS DESCRIPTION REFERENCE No. Q'ty
40 Chip Capacitor 0.1u-Z F 25V 1608(0603)
C2 C5 C7 C16 C19
C20 C21 C22 C24
C30 C33 C34 C39
C49 C51 C52 C53
C54 C55 C56 C57
C58 C60 C62 C63
C64 C65 C66 C67
C68 C69 C71 C72
C73 C74 C75 C76
JP5 JP6
39
41 Chip Capacitor GRM188B11A105KA61D (1.0u-K B) 1608(0603) C6 C77 C78 C79 4
42 Chip Capacitor open-c 1608(0603)
C1 C13 C35 C36
C37 C50 C59 C61
C70 C84
0
43 Film Capacitor 1500p-K 100V (50V) Radial Pitch=5mm C15 1
44 Resistor 18-J 2W Lead-form : Floated type pitch=15mm R54 1
45 Chip Resistor 0ohm 1608(0603) R307 1
46 Chip Resistor 10-J 1608(0603)
R70 R71 R72 R73
R50 R51
6
47 Chip Resistor 220-J 1608(0603) R13 R66 R309 3
48 Chip Resistor 470-J 1608(0603) R312 1
49 Chip Resistor 620-J 1608(0603)
R25 R74 R75 R76
R77 R78 R79 R80
R81
9
50 Chip Resistor 1k-J 1608(0603) R1 R311 R68 3
51 Chip Resistor 2.2k-J 1608(0603) R23 R24 R310 3
52 Chip Resistor 5.6k-J 1608(0603) R46 R47 2
53 Chip Resistor 8.2k-J 1608(0603) R30 R31 2
54 Chip Resistor 10k-J 1608(0603)
R4 R14 R26 R28
R34 R35 R43 R52
R53
9
55 Chip Resistor 20k-J 1608(0603) R33 1
56 Chip Resistor 22k-J 1608(0603) R21 R22 R44 R45 4
57 Chip Resistor 33k-J 1608(0603) R48 R49 2
58 Chip Resistor 47k-J 1608(0603)
R5 R6 R7 R16 R29
R60 R61 R82 R83
R84 R85 R86
12
59 Chip Resistor 330k-J 1608(0603) R3 1
60 Chip Resistor 470k-J 1608(0603) R2 1
61 Chip Resistor 510k-J 1608(0603) R27 1
62 Chip Resistor 1M-J 1608(0603) R65 1
63 Chip Resistor 15k-F 1608(0603) R36 1
64 Chip Resistor 22k-F 1608(0603) R55 1
65 Chip Resistor 100k-F 1608(0603) R313 1
66 Chip Resistor 110k-F 1608(0603) R32 1
67 Chip Resistor 240k-F 1608(0603) R37 1
68 Chip Resistor 390k-F 1608(0603) R314 1
69 Chip Resistor open-r 1608(0603)
R8 R9 R10 R15 R38
R39 R40 R41 R42
R56 R58 R59 R62
R63 R64 R67 R69
R308 JP1 JP2 JP3
JP4
0
70 TACT SW *13 1104RTA-2
SW1 SW2 SW3
SW4 SW5
0
TACT SW *13 SKRGAED010
SW1 SW2 SW3
SW4 SW5
5
TACT SW *13 EVQ11L05R
SW1 SW2 SW3
SW4 SW5
0
71 Potentiometer *9 RK09D1130 (LM=20) 50k-B 16detent vertical VR1 1
Potentiometer *9 RV09BF-40E1-115F-0B50K-0G31 50k-B 16detent vertical VR1 0
Potentiometer *9 F-09115N-2+16C B50k-a0 L10FCx4.5(T) 50k-B 16detent vertical VR1 0
72 Rotary Encoder F-11EN7H20M+C L15Fx7(0) Vertical type SW6 1
73 Stereo Phone Jack *10 SJ-6325-B J1 J4 2
Stereo Phone Jack *10 YKB21-5010 J1 J4 0
74 Stereo Phone Jack *11 SJ-6325-4P with SW J2 1
Stereo Phone Jack *11 YKB21-5074 J2 0
75 DC Jack *12 DC-208B J3 1
DC Jack *12 HEC2305-016250 J3 0
DC Jack *12 SCD438CCS0033B00G J3 0
DC Jack *12 DS-208 D=2.0mm J3 0
76 JP open-jp Pitch=5mm L5 L8 0
77 PCB PCB-0169 (23) FR-4 2layer, Weight is 90g 1
- 21 -

Zoom G1 Specifications

General

Simultaneous Effects	5
A/D Conversion	24-bit
D/A Conversion	24-bit
Input Impedance	1 MΩ
Output Impedance	1 kΩ
Patch Memory	40
Weight	350g (without batteries)
Inputs	1/4" phone jack
Outputs	1/4" phone jack
Effects Types	Compressor, Overdrive, Distortion, EQ, Chorus, Flanger, Phaser, Tremolo, Vibrato, Delay, Reverb
