Zoom G1 User Manual

MECHANICAL PARTS LIST
No. PART NAME SUB DROWING NO MATERIAL DESCRIPTION Q'TY
1 G1 TOP CASE Z2B-0226 ABS (natural)
(1) paint & silk prin
t
Surface :Silver
1
2 BOTTOM CASE Z2A-0125 SECC t=0.8 (2) 1
3 FOOT SW Z2B-0227 ABS (black) (3) 2
12 FOOT SW RUBBER Z2D-0067 TPE (yellow or white) (3) 2
4
VR KNOB 1
Z2B-0228-B ABS (black) (4) 1
5
VR KNOB 2
Z2B-0229 ABS (balck) (5) 1
8
PCB SPACER
Z2B-0232 ABS (Chromium coating) (6) 2
9
FOOT SW PLATE R include TACT SW
BUTTON
Z2B-0233 ABS (black) (7) 1
10 G1 DISPLAY SHEET Z2E-0216
PCV / with adhesive tap
e
φ
40mm t=1.0mm
(8) with silk print :3 colors 1
11
FOOT SW PLATE L include TACT SW
BUTTON
Z2B-0234 ABS (black) (9) 1
13 FOOT SW SPRING Z2A-0126 SUS 304 WPB d=0.8 (10) 2
6
BATT CASE
Z2B-0230 ABS (black) (11) 1
7
BATT CASE COVER
Z2B-0231 ABS (black) (12) 1
20 BATTERY CUSHION Z2E-0190 sponge 73.4X10.2x3(t)mm with adhesive tape (12) 2
14 BATT SPRING (+) Z2A-0127 SUS304 d=0.7 (13) 1
15
BATT SPRING (-) Z2A-0128 SUS304 d=0.7 (14)
1
16 BATT SPRING (+/-) Z2A-0129 SUS304 d=0.7 (15) 1
18 FOOT RUBBER 1-L Z2D-0068 Sponge rubber, H=40, with adhesive tape (16) 1
19 FOOT RUBBER 2-L Z2D-0069 Rubber, H=60, with adhesive tape (17) 1
21 FOOT RUBBER 1-R Z2D-0070 Sponge rubber H=40, with adhesive tape (18) 1
22 FOOT RUBBER 2-R Z2D-0071 Rubber H=60, with adhesive tape (19) 1
24 SUPPORT FOOT RUBBER Z2D-0072 6*20*3.3mm, H=65, with adhesive tape (20) 2
17 SCREW M3X8 P-tight (21) 8
23 SCREW M3x10 P-tight (22) 2
PACKING PARTS LIST
No. PART NAME SUB SPECIFICATIONS MATERIAL DESCRIPTION 120US Q'TY
1 G1 Gift Box Z2F-0046 corrugated cardboard. Printing color : 4C 1
G1 AC Adapter Spacer Z2F-0057 corrugated cardboard, A3b, T=3mm Printing color : Black 1
2 G1 MASTER Carton Box Z2F-0047 double wall corrugated cardboard. Printing color : Black 0.1
3 Poly Bag for Unit 200X300mm 1
4 Poly Bag for Manual 200X300mm (for A5 size) 1
5 Serial Label for Carton Box Z2E-0192 0.1
6 Serial Label for Unit Z2E-0193 2
7 G1 JAN Bar-Code Label Z8F-0084-A4 for CM 0
G1 JAN Bar-Code Label Z8F-0084-A4 for 120US 2.1
G1 JAN Bar-Code Label Z8F-0084-A4 for 120GL 0
G1 JAN Bar-Code Label Z8F-0084-A4 for 220BX 0
G1 JAN Bar-Code Label Z8F-0084-A4 for 240UK 0
8 G1 USA Bar-Code Label for Gift Box A69 1
G1 USA Bar-Code Label for Carton Box A69 0.1
9 FCC Label Z2I-0729 Aluminum label 1
10 Destination Label Z2E-0194 for CM 0
Destination Label Z2E-0194 for 120US 0.2
Destination Label Z2E-0194 for 120GL 0
Destination Label Z2E-0194 for 220BX 0
Destination Label Z2E-0194 for 240UK 0
11 G1/G1X Operation Manual G1/G1X-5010-1
paper of fine quality, A5 28page,
Warrant
y
Card JP sticks on a back cover.
JAPANESE 0
12 G1/G1X Operation Manual G1/G1X-5000-1 paper of fine quality A5 28page ENGLISH 1
13 G1/G1X Operation Manual G1/G1X-5002-1 paper of fine quality A5 28page GERMAN 0
14 G1/G1X Operation Manual G1/G1X-5003-1 paper of fine quality A5 28page FRENCH 0
15 G1/G1X Operation Manual G1/G1X-5004-1 paper of fine quality A5 28page ITALIAN 0
16 G1/G1X Operation Manual G1/G1X-5005-1 paper of fine quality A5 28page
SPANISH
0
17 G1/G1X Operation Manual G1/G1X-5006-1 paper of fine quality A5 28page
PORTUGUESE
0
18 G1/G1X Operation Manual G1/G1X-5007-1 paper of fine quality A5 28page CHINESE 0
19 Warranty Card US Z2I-0730 Stamp: none for US 1
20 G1/G1X Patch List Sheet Z2I-0725
A4 Both side printing
Language:Japanese and English
1
21 G1 Logo Label for Unit Z2E-0216 Aluminum label 1
22 G1/G1X Display signal chart sheet Z2I-0726 Film-coated paper Both side printing 1
23 AC Adaptor
AD-0006D for 120US and
120GL
with gift box Supplied by ZOOM 1
24 AC Adaptor AD-0006E for 220BX with gift box Supplied by ZOOM 0
25 AC Adaptor AD-0006F for 240UK with gift box Supplied by ZOOM 0
26 ZOOM Logo Tape Z2E-0218 0.005
- 22 -

Zoom G1 Specifications

General

Simultaneous Effects	5
A/D Conversion	24-bit
D/A Conversion	24-bit
Input Impedance	1 MΩ
Output Impedance	1 kΩ
Patch Memory	40
Weight	350g (without batteries)
Inputs	1/4" phone jack
Outputs	1/4" phone jack
Effects Types	Compressor, Overdrive, Distortion, EQ, Chorus, Flanger, Phaser, Tremolo, Vibrato, Delay, Reverb
