Quick Guide 2
4-track mode basic operation
ZOOM H4
22
2.
Move the jog dial up/down to bring
the cursor to “SOURCE”. Then press
the jog dial.
The input source can now be selected.
In 4-track mode, the following selections are
available.
HINT
• When IN1&2 or MIC is selected, the input mixer
will receive two signals.
• The built-in stereo mic always feeds the two L/
R channels as a set.
3.
Move the jog dial up/down to select
the input source, and then press the
jog dial.
The selection is accepted.
4.
Press the center of the [MENU] key
to return to the 4-track mode top
screen.
5.
To select the recording track, use the
TRACK [1] – [4] keys and press the
respective key repeatedly until it is lit
in red.
In 4-track mode, the TRACK [1] - [4] keys serve
to switch the status (record/playback condition)
of tracks 1 - 4. Each push of the key cycles
through the following three status settings.
For example, when you press the TRACK [1]
key so that it is lit in red, the display changes as
follows.
HINT
•To record two different instruments
simultaneously on two tracks, select a track
pair (tracks 1/2 or 3/4) as recording target
(
→
p. 50).
•To record the sound source in stereo, you can
use a function called “stereo link” to link a track
pair (tracks 1/2 or 3/4) and use them as a stereo
track (
→
p. 53).
Adjusting the input sensitivity/
recording level
1.
To adjust the input sensitivity of the
input source, use the [MIC GAIN]
switch, [INPUT 1 GAIN] switch, or
[INPUT 2 GAIN] switch.
When recording with the built-in stereo mic, use
Display
Input source
Input 1 Input 2
MIC
Built-in stereo mic L Built-in stereo mic R
IN1&2
[INPUT 1] jack [INPUT 2] jack
IN1
[INPUT 1] jack
IN2
[INPUT 2] jack
TRACK [1] – [4] keys
Out Lit in red Lit in green
Mute Recording Playback
enabled
Name of file recorded
on track
Recording target
track
H4_E.book 22 ページ ２００６年９月１日 金曜日 午後７時５６分
