Zoom Handy Recorder H4 User Manual

ZOOM H4
89
Effect Types and Parameters
Effect types and parameters in 4-track mode
PREAMP module
●
Guitar preamp effect types
FD CLEAN Clean sound of Fender TwinReverb ('65)
VX CLEAN Clean sound of Vox AC30
HW CLEAN Clean sound of Hiwatt Custom 100
UK BLUES Crunch sound of Marshall 1962 Bluesbreaker
BG CRUNCH Crunch sound of Mesa Boogie MK III
MS #1959 Crunch sound of Marshall 195.9
PV DRIVE High-gain sound of Peavey 5150
RECT VNT
High-gain sound using the red channel of Mesa Boogie Dual Rectifier
(Vintage mode)
DZ DRIVE High-gain sound of Diezel Herbert channel 3
TS+FD_CMB Combination of Fender Combo amp and Ibanez TS-9
SD+MS_STK Combination of Marshall stack amp and Boss SD-1
FZ+MS_STK Combination of FuzzFace and Marshall stack amp
The above 12 effect types have the same parameters.
(1) CABINET
0 –2
(2) GAIN
0 – 100
Adjusts the intensity of the speaker cabinet sound. Adjusts the preamp gain (distortion depth).
(3) BASS
-12 – 12
(4) MIDDLE
-12 – 12
Adjusts boost/cut in the low range. Adjusts boost/cut in the middle range.
(5) TREBLE
-12 – 12
(6) LEVEL
1 – 100
Adjusts boost/cut in the high range.
Adjusts the level of the signal after passing the
PREAMP module.
(7) ZNR (ZOOM Noise
Reduction)
OFF, 1 – 16
Adjusts the sensitivity of the noise reduction circuit
developed by ZOOM.
ACO SIM This effect makes an electric guitar sound like an acoustic guitar.
(1) TOP
0 – 10
(2) BODY
0 – 10
Adjusts the characteristic string tone of the acoustic
guitar.
Adjusts the characteristic body tone of the acoustic
guitar.
(3) BASS
-12 – 12
(4) MIDDLE
-12 – 12
Adjusts boost/cut in the low range. Adjusts boost/cut in the middle range.
(5) TREBLE
-12 – 12
(6) LEVEL 1 – 100
Adjusts boost/cut in the high range.
Adjusts the level of the signal after passing the
PREAMP module.
H4_E.book 89 ページ ２００６年９月１日 金曜日 午後７時５６分
