Zoomlion RT60 Maintenance And Service Manual

Edition 2 Chapter 3 Page 3-36
Feb/2013 Inspection [document code]
Table 3-3
Parts Inspected items Parts Inspected items
DrivingEquipment
Examine the function of
the left and right
joysticks.
Derricking
Mechanism
Derricking cylinder
• Examine the
articulated pin
spindle for wear
and damage.
• Examine the lock
bolt of articulated
pin spindle for tight
fit.
• Examine it for
leaks.
• Examine it for
abnormal unusual
vibration and noise.
• Make sure that the
cylinder retracts.
• Examine the hoses
for aging, distortion
and deformation.
PTO
• Examine it for
tight fit and leaks.
• Examine it for
abnormal
unusual noise
and heating.
Drive lines
• Examine the
flange and
connectors for a
tight fit.
• Examine it for
vibration, scrape
and wear.
Hydraulic System
Hydraulic reservoir
• Examine it for
tight fit and
damage.
• Examine it for
cracks and leaks.
• Examine the oil
level, pollution
grade and
viscosity.
Balance valve
• Examine it for
leaks.
• Examine the pipe
fittings for correct
seating.
Hydraulic pump
• Examine it for
tight fit and
damage.
• Examine it for
abnormal
unusual noise,
vibration and
heating.
• Examine it for
leaks.
• Make sure that
the suction pipe
inhales air.
• Make sure that
the output
pressure is
Boom Extend /
Retract
Mechanism
Boom (4 sections)
• Examine it for
cracks, bends and
damage.
• Examine the lock
bolts of the
articulated pin
spindle for tight fit.
• Examine the sliding
surface for scrapes.
• Examine the
articulated pin
spindle liner for
wear and damage.
• Make sure that the
sliding surfaces
have lubricant on
