Zoomlion RT60 Maintenance And Service Manual

Edition 2 Chapter 2 Page 2-1
Feb/2013 Troubleshooting
Troubleshooting
2.1 ELECTRICAL SYSTEM
Table 2-1
Part Problem Cause Remedy
Electrical System
Work light does not
illuminate
a) Bulb damaged
b) FU811 burnt out
c) Poor grounding
d) Conducting wire broke
e) Switch defective
Replace
Repair
Repair
Repair
Replace
Vehicle length indicator
does not illuminate
f) Bulb damaged
g) Switch defective
h) Conducting wire broke
Replace
Repair
Replace
Interior light does
notilluminate
a) Bulb damaged
b) Switch defective
c) Conducting wire broke
d) FU85 burnt out
Replace
Replace
Repair
Replace
Instrument lights do not
illuminate
a) Bulb damaged
b) Switch defective
c) Conducting wire broke
d) FU811 burnt out
Replace
Replace
Repair
Replace
Combination instruments do
not illuminate
a) Conducting wire broke
b) FU66 burnt out
c) FU61 burnt out
d) Instruments damaged
Repair
Replace
Replace
Replace
Windshield wiper does not
operate
a) FU86 burnt out
b) Switch defective
c) Damage to the motor
Replace
Replace
Replace
Horn does not operate
a) FU87 burnt out
b) Switch defective
c) Relay defect
d) Conducting wire broke
e) Horn damaged
Replace
Replace
Replace
Repair
Replace
Anti-two block switch does
not operate
a) See the error codes that the
RCI display shows
b) Winding reel defective
c) Conducting wire broke
Repair
Repair or replace
Repair
