User Manual ZFG 3.0
- 23-
Table A
Number of authoritative traffic load
construction class
more than 3200
SV
1800 to 3200
I
900 to 1800
II
300 to 900
III
60 to 300
IV
10 to 60
V
up to 10
VI
Table B
Road type
construction class
Highway
SV, I, II
main street, walking path with a heavy traffic load
II, III
walking path with traffic load
IV
service road, walking path
V
service road, Wheelchair-accessible residential street
VI
Section 14.3.5
Table 9: Guide value for correlation of static deflection modulus Ev2 or dynamic deflection
modulus Evd to compaction ratio Dpr for course-grained soils groups
Soils group
Static deflection modulus Ev2 in
MN/m²
Dynamic deflection modulus Evd
in MN/m²
Compaction ratio Dpr in
%
GW, GI
≥ 120
≥ 65
≥ 50
≥ 40
≥ 30
≥ 103
≥ 100
≥ 98
≥ 97
≥ 100
≥ 80
≥ 70
GE, SE,
SW,SI
≥ 80
≥ 70
≥ 60
≥ 50
≥ 40
≥ 35
≥ 100
≥ 98
≥ 97
