Zubler Z4 VARIOmatic - Basic Functions; Vacuum Levels

16
T1 T2
-
+
Mehrplatz - Einzelplatz (Anlage)
Level suction power
1 20 l/s
2 25 l/s
3 30 l/s
4 35 l/s
5 max 50 l/s
2.3.1 Vacuum levels
Q As long as the power limit of the suction
motor is not reached (depending on
the number of simultaneously opened
workstations), the following volume flows
can be achieved approximately with the 5
factory set vacuum levels:
Q Vacuum level 5 is the maximum motor
power (no volume control).
Q The specified air volumes are determined
by the attached vacuum and refer to
the port valve diameter of the AP601
automatic port opener.
2.3 Basic functions
Q The suction power of the vacuum levels
1-4 can be changed via the Zubler suction
technology APP.
