5
0.2 Intended purpose of use
0.3 Operating Environment
Temperature: +5°C bis +40°C
Max. permissible relative humidity: max. 80% (bei 30°C)
Voltage supply 230V AC +/-5% 50-60Hz
Total connected load : 10A
Compressed air, free of oil and moist min.5,0bar
This suction system is designed exclusively for dry dusts!
The Z4 VARIOmatic is a central suction system for the simultaneous operation
of a maximum of 4 workstations and can be used for up to 10 alternatively used
stations.
The suction system consists of the central suction unit Z4 and port openers
AP601 connected to the suction system via network cable.
The suction system allows working with 5 vacuum levels as long as only one
workstation is opened.
With simultaneous operation of 4 workstation, all stations have regardless of
their setting, the same suction power which corresponds to suction level 2
(factory setting).
