2N Access Unit M User Manual

Current consumption [A] Available power output [W]
1 12
Cabling Description
Figure 1. Cable connection for Part Nos.
9161121, 9161141, 9161151, 9161161
The LAN cable is 3 m long and RJ-45 male termina-
ted. All the other available cables are 35 cm long.
Figure 2. Cable connection for Part
Nos. 916112, 916114, 916115, 916116
The LAN cable is RJ-45 female terminated. All
the available cables are 35 cm long.
Installation
31

2N Access Unit M Specifications

General

Brand	2N
Model	Access Unit M
Category	IP Access Controllers
Language	English
