InputState
The block defines the condition to be met in case the defined logic level InputState
gets connected to the defined digital input.
Input parameters
– define the digital input.Input
Valid values:
– tamper switchtamper
– digital input 1input1
– digital input 2input2
– digital input 1 on card readercr_input1
– digital input 2 on card reader.cr_input2
There may be different lists of valid values for different intercom 2N IP
models; refer to the Available Digital Inputs and Outputs subsection.
– define the required digital input level. The parameter is optional.Level
Valid values:
– logic 0lo
– logic 1 (default value).hi
Output parameters
Out
Example
The condition is met for an activated tamper switch (device not open):
