2N IP Solo - Security Relay Management; Installation and Connection; Status Signalling

Installation manual 2N® IP Solo
52 / 74
•
•
•
Installation:
Install the2N
®
IP Intercom Security Relayonto a two-wire cable between the intercom and
theelectric lock inside the area to be secured (typically behind the door). The device is
poweredand controlled via this two-wire cable and so can be added to an existing installation.
Thanksto its compact dimensions, the device can be installed into a standard mounting box.
Connection:
Connect the2N
®
IP Intercom Security Relayto the intercom as follows:
To the intercom active output (OUT1)
Connect the electric lock to the2N
®
IP IntercomSecurity Relayoutput as follows:
To the switched output.
To the passive output in series with the external power supply.
The device also supports a Departure button connected between the ‘PB’ and ‘- Helios IP/IP
Intercom’terminals. Press the Departure button to activate the output for 5 seconds.
Status signalling:
Green LED Red LED Status
blinking off Operational mode
on off Activated output
blinking blinking Programming mode – waiting for
initialisation
on blinking Error – wrong code received
