3D Systems ProX User Manual

3D Systems, Inc. p/n 77-D005 Rev_A
Ethernet Adaptor (3x): Network connections to service 1 printer and a laptop (for service personnel only) .
USB Adapter
4-Pin Connector for Oxygen Sensor
Nitrogen Inlet: Input for nitrogen supply .
Quick-Disconnect Air Fitting: Input for compressed air coming into the MQC System
Pressure Regulator (Nitrogen)
Pressure Regulator (Air)
Pressure Regulator (Air)
Transport Filter: The material filter for the ProX® MQC Single Use System .
PROX® MQC SINGLE USE SYSTEM COMPONENTS
ProX® MQC Single Use System User Interface
The User Interface, located on the front panel of the ProX
®
MQC Single Use System, consists of a dial-operated menu screen
that allows the user to access the functionality of the system . An E-Stop control is located to the right of the screen and the
system power switch is located to the left .
B
C
D
A
A
B
C
D
E
F
G
H
I
