Pannoramic 1000 1.2 – User’s Guide 3.2 Preparing Magazines
Figure 8 – Inserting a standard slide into a magazine
Figure 9 – Inserting a large slide into a magazine
Warning!
Make sure that placing the magazine by reading UP SIDE at the top
when inserting standard, or at the left of the magazine when inserting
large slides. The cover slip and the label area should be on the top,
with the label area pointing outwards.
March 19, 2019 – Rev. 2 3DHISTECH Ltd. 27(78)
