Pannoramic 1000 1.2 – User’s Guide 3.2 Preparing Magazines
4. Once you have inserted all the required magazines, close the door (1) by sliding it to the
right.
Warning!
Never open the front door unless prompted accordingly by software.
When you open the door at any other time, make sure not to reach with
your hands into the instrument to avoid the risk of crushing your fingers.
Remove magazines
1. If the door opener button is lit green, push the door opener button (1).
2. Open the magazine compartment door (2) by sliding it to the left.
3. Remove magazine(s) from their slots in the compartment (3). Grab the magazine firmly
while removing it, but so that the inserted slides do not fall out.
Note:
The magazine compartment door is equipped with an interlock switch.
It can be opened only if a running digitization process has ended or
interrupted.
March 19, 2019 – Rev. 2 3DHISTECH Ltd. 29(78)
