Receiver Battery Installation
Remove cap from receiver handle.
Install eight ‘AA’ cell batteries (LR6) into the battery holder as indicated by the polarity
symbols (+ and –).
Attach battery holder to the PP3 connector in the receiver handle, and slide holder into
the handle. Replace the cap.
8 “AA” Alkaline Batteries
1. Twist cap to open battery
compartment.
2. Slide battery compartment
out of handle.
m Caution
To reduce the risks associated with fi re and explosion:
• Do not short, excessively heat, or dispose of batteries in fi re.
• Install batteries with proper polarity.
• Use only Alkaline "AA" (LR 6) sized batteries.
• Do not charge batteries
• Do not use leaking batteries
To reduce the risks associated with environmental contamination:
• Dispose of batteries and electronic components in accordance with all regulations.
• Ensure batteries are installed with correct polarity.
• Always remove batteries when storing the units for long periods of time.
The receiver batteries are tested for two seconds every time the unit is turned on.
The bar graph on the screen will fill to the relative battery level.
The Battery Icon [8] on the Locate Screen will continuously indicate the battery level.
Cleaning
To clean the unit, wipe with a damp cloth.
