3M Dynatel 955 User Manual

Operation
Section 1
Page 30
RFL Example 3, continued
Fault Locate – Multiple Gauge
4. Set up for the third section:
Strap
Test
Set
22 AWG
or .7 mm
unknown1179 ft or 359 m
24 AWG
or .5 mm
205 ft or 63 m
26 AWG
or .4 mm
Pick section 3 gauge
Use arrow keys to line
up ✽ with 22 AWG or
.7 mm.
Length of section 3 –
unknown
On multiple gauge fault
locate, one section must be
entered as “unknown,”
even if you know it.
continued on next page...
continued from previous page...
For this example, use
22 AWG or .7 mm.
