3M Dynatel 955 User Manual

Operation
Section 1
Page 29
RFL Example 3, continued
Fault Locate – Multiple Gauge
3. Set up for the second section:
1179 ft or 359 m
24 AWG
or .5 mm
Strap
Test
Set
205 ft or 63 m
26 AWG
or .4 mm
Use arrow keys to line
up ✽ with 24 AWG or
.5 mm
Length of section 2
For this example, use
24 AWG or .5 mm.
Use keypad to enter
length of section:
1179 ft or 359 m.
Pick section 2 gauge
continued on next page...
