Operation
Section 1
Page 28
RFL Example 3, continued
Fault Locate – Multiple Gauge
2. Set up for the first section:
Strap
T
est
Set
205 ft or 63 m
26 A
WG
or .4 mm
Pick section 1 gauge
Use arrow keys to line
up
✽
with 26 A
WG or
.4mm
continued on next page...
For this example, use
26 AWG or .4 mm.
Use keypad to enter
section length: 205 ft
or 63 m.
Section 1 length
