7 SPECIFICATIONS HoloSea S7
7 Specifications
Optical Resolution 1.5 microns
Laser pulse rate 0.5 µs
Tow rate 8 knots
Point source wavelength 405 nm
Power < 5 Watts
Power requirement 120/240 VAC
Communication 13 pin SeaConn Ethernet connector
Data transfer Gigabit Ethernet
Computer operating system Windows 7 64-bit or later
Hologram size 2048x2048
Frame rate 22 fps
Sample space 15 mm
Sample volume up to 100 microlitres
Size 92mm x 351mm
Weight in air (water) 2.6 kg (0.5 kg)
