5 | TECHNICAL SPECIFICATIONS
ANTMIX 6FX ANTMIX 8FX ANTMIX 12FX
MONO mic/line
inputs
2 2 with compressor 4 with compressor
Mic mono/stereo line
inputs
- 2 2
Stereo line input 2 1 2
Power supply 18V~ 1A - External PSU 18V~ 1A - External PSU 100-240V~ 50-60Hz
Fuse T1.6A L 250V~
Power Consumption 17W max 24W max 40W max
Dimensions
(W x H x D)
196 x 68 x 243 mm 255 x 68 x 342 mm 340 x 100 x 416 mm
Weight 1,18 Kg 1,98 Kg 3,53 Kg
Microphone input
Connector Balanced XLR
Impedance 1.8 kΩ
Frequency response 20~20kHz +/-1dB
Distortion (THD + N) <0,03% @ +0dB, 22~22 kHz, A weighted
Gain 0~55dB
Max input +15dB (balanced)
Low-cut 75Hz 12dB/oct.
Signal-to-noise ratio <-100 dBr A weighted
Phantom powering +48V
Line input
Connector Balanced 6,35mm (1/4”) - unbalanced RCA
Impedance 10 kΩ
Frequency response 20~20kHz +/-1dB
Distortion (THD + N) <0,03% @ +0dB, 22~22 kHz, A weighted
Gain +15dB~-35dB
Signal-to-noise ratio <-100 dBr weighted A
Common specication
Compressor
(only for channels
featuring this control)
Gain: 0 ---> 9 dB | Soglia: 20 dB ---> 5 dB
Hum & noise
< -80dB
(A weighted, full bandwidth, 1 channel and MAIN @ 0dB,
other channels @ minimum)
Crosstalk
< -80dB
(A weighted, full bandwidth, 1 channel and MAIN @ 0dB,
other channels @ minimum)
Equalization
Mono & mono/stereo
channels
+/-15 dB @12 kHz
+/-15 dB @2.5 kHz
+/-15 dB @80 Hz
Stereo channels
+/-15 dB @12 kHz
+/-15 dB @80 Hz
2-TRACK IN
Connector 2 x unbalanced RCA
Impedance 10 kΩ
Frequency response 20~20kHz +/-1dB
Distortion (THD + N) <0,03% @ +0dB, 22~22 kHz, A weighted
Gain OFF~+15dB
