CLEANINGTHECOMBUSTIONCOMPONENTS

Procedureforcleaningthefan,burner,FlameSensorandAFR,asusedbyallServiceRepresentatives.



1) TOOLS

‐Gatherthefollowingmaterialstogether:

a. Degreaserinapumpactionbottle,Sandpaper,Philips ScrewDriver,Needle‐NosedPliers,Duct

Tape,Flashlight,AirCompressor,ShopVacuum,3xTowels



2) POWER

‐Disconnectpowertoyourunitbyeitherunpluggi ngitfromthewalloutlet,orbythecircuit

breaker,dependingonthesetup.



3) GAS

‐Shutoffthegassupply.



4) FRONTCOVER

‐Removethefrontcover.



5) MANIFOLDPLATE/GASVALVEASSEMBLY

‐

a. Removethemanifoldplatescrews.TheyarewidepanheadPhilipsscrews,locatedonthe

edgesofthestampedmetalplateofthegasmanifold



b. Removethebrassgasvalvescrew.

c. RemovethewireholdingtheEasy‐Linkwiresinplace.

d. Disconnecttheclearplastictubefrombeneaththecombustionchamber

e. Gentlyliftupthemanifold&gasvalveassemblytodislodgeitfromthegasinlet,andgentlyletit

hang.

i. Thereisasmallfilterscreeninthebottomofthegasinlet.Donotloseit.



Figure25

Figure26
