108
COMMAND
NAME
DESCRIPTION No.
COMMAND SYNTAX
Command Argument 1 Argument 2 Argument 3 Argument 4 Response
Compose
Mixture
Sets/Reads Gas Mixture
Parameters
Command submitted with all 4
arguments writes a new User
Defi ned gas mixture
(up to 5 Gas components) with
the specifi ed gas ratios, gas
mixture name (up to 6 charac-
ters), and gas mixture number
(200-219).
It also can be used to update
or delete a currently selected
User Defi ned gas mixture.
Argument#1 - Decimal string
with new Gas Mixture index
[200 - 219]
Argument#2 - string with ';'
delimited gas components
indexes.
Argument#3 - string with ';'
delimited gas components
ratios (number of components
should be the same as in Argu-
ment#2) Argument#4 - string
with new Gas mixture name (up
to 6 characters long).
34 CM
No Argument
(Checks how many Gas
Mixtures currently saved
in the EEPROM [0-20])
CM:<number of mixtures>
Example: CM:3
D
Delete last (highest index)
Gas Mixture in the GM table
CMD:<index>
Example: CMD:202
<Gas Mixture Index>
Check Name and number of
components for particular
Gas Mixture Index [200-219]
CM:<index>,<comp#>,<name>
Example: CM:200,4,MyMix1
<Gas Mixture Index>
List all components gas
indexes and ratios for
particular Gas Mixture Index
[200-219].
C
CMC:<index>,<comp#>,<G1>,
<R1>,<G2>,<R2>,<Gn>,<Rn>
,..
.,<mixture name>
Example: CMC:200,2,0,65.0,4,
35.0,MyMix2
<New Gas Mixture Index>
Create New Gas Mixture. All
4 Arguments are required for
this command.
NOTE: number of Gas
components indexes must be
equal to number of ratios.
NOTE: Sum of Gas
components ratios must
be equal to 100%.
List of Gas
Components
Indexes
(Semicolons (;)
delimited)
List of Gas
Components
Ratios
(0.01-99.99%)
(Semicolons (;)
delimited)
<Mixture
Name>
(Only up to 6
characters
long)
CM:<new mix index>, <name>,
<number of components>
Example: CM:201,MyMix3,5
