73
***********************
Event Reg. Has
been reset!
***********************
Press any Key...
To disable a latch feature, the corresponding asterisk must be removed. Use the ENT
button to accept and save new Latch Alarm Event Register settings in the controller’s
non-volatile memory.
d) Reset Status Alarm Event Register (Tabular entry)
The Status Alarm Event Register can be reset by selecting the “Reset Alarm Event
Reg”menu option. A typical display with the Status Alarm Event Register reset screen
is shown in Figure 46. Note that it requires confi rmation from the user:
Reset Alarm Events Reg.:
NO
YES
DO YOU WANT
RESET EVENT REG?
Figure 46: Resetting Alarm Events Register
Once the “YES” option is selected, the Event Register will be reset, and the following
confi rmation screen will appear:
Figure 47: Alarm Event Register Reset Confi rmation
NOTE: Any Alarm Events that may have occurred (Event 0 to Event D) are
stored in the internal status register. All detected events (if corresponding
bit in the latch register is not masked) remain stored until the register is
manually reset (by means of the digital communication interface). If the event
corresponding bit in the latch register is masked (disabled), the event will be
indicated as long as it is active (no latching). The status Alarm Event Register
is mapped to the SRAM (volatile memory). In case of power interruption, the
status Event Register will be automatically reset.
