93
COMMAND
NAME
DESCRIPTION No.
COMMAND SYNTAX
Command Argument 1 Argument 2 Argument 3 Argument 4 Response
Relay
Assignment
Read / Set SSR Relay
Assignment
D - no action (SSR disabled*)
FL - Low fl ow alarm
FH - High fl ow alarm
FR - Range between High & Low fl ow alarms
PL - Low pressure alarm
PH - High pressure alarm
PR - Range between High & Low pressure alarms
TL - Low temperature alarm
TH - High temperature alarm
TR - Range between High & Low temperature alarms
T1 - Tot#1 reading > limit
T2 - Tot#2 reading > limit
PO - Pulse Output
AE - Alarm Events
DE - Diagnostic Events
M - Manual On (energized)
NOTE: when SSR is energized,the normally open contact
is closed.
14 R D R:D
FL R:FL
FH R:FH
FR R:FR
PL
R:PL
PH R:PH
PR R:PR
TL R:TL
TH R:TH
TR
R:TR
T1 R:T1
T2 R:T2
PO R:PO
AE R:AE
DE R:DE
M R:M
S
(read current
settings)
R:D
