Manual RF Signal-
Generator
6.4. Program Mode
Figure: SW-04
(1) List of available batch programs. Double-clicking activates the corresponding program.
(2) An external reference of 10 MHz may be selected here.
(3) Display of the current frequency and power output.
(4) Opens the batch program editor.
The signal can be switched on and off at the output using the RF on/off button – refer to
Figure: SW-02 (3).
1
2
3
4
